• Power Range: 521 – 680 HP across four models (1151, 1156, 1162, 1167)
• Engine: MAN 6-cylinder with Fendt iD™ low engine speed concept for reduced fuel consumption
• Max. Torque: 1,844 – 2,286 ft·lb @ 1,450 RPM
• Transmission: Fendt VarioDrive™ — stepless CVT from creep speed to 25 mph
• Fuel Capacity: 361 gal (1,370 L)

Hydraulics & Hitch

• Hydraulic Flow: 58.1 gpm standard — optional dual pump at 116 gpm
• Working Pressure: 2,900 psi · up to 8 rear valves
• Rear 3-Point Lift: Steerable — 20,000 lbs continuous lift capacity

Dimensions & Weight

• Operating Weight: 43,500 lbs empty · 59,000 lbs max. permissible
• Footprint: 266 in L × 141.8 in W × 141 in H
• Ground Clearance: 14.1 in

• FendtONE™ Workstation: All-new cab design with customizable FendtONE system with up to two 12-inch in-cab monitors, multi-function joystick, and configurable interface to match operator workflow
• UltraVision LED Lighting: 360° CAN-based lighting system delivering up to 87,300 lumens with customizable work-light profiles for full-field visibility day or night

Implement Control

• Hydraulically Controlled Drawbar: Optional system with four modes for improved pulling performance — includes new mode linking drawbar swivel angle to tractor steering angle
• Dual Variable Displacement Pump: Optional second pump doubles hydraulic capacity to 116 gpm (220 + 220 L/min) for high-demand implements
• Steerable 3-Point Hitch: 20,000 lbs continuous rear lift capacity with steerable geometry for precise implement tracking

Suspension & Undercarriage

• SmartRide+ Suspension: Optional load-leveling system using hydraulic cylinders in the hardbar suspension to raise and lower the front end — improves weight distribution, traction, ride quality, and overall performance
• Mobil-Trac™ System: Pivoting midwheels with 11° of track-to-track oscillation for superior traction, reduced slip, optimum soil conservation, and a smoother ride across variable terrain

Drivetrain

• VarioDrive Drivetrain: Seamless, stepless CVT operation from creep speed (65 ft/hr) to 25 mph — updated gear ratio on the 1167 MT puts 45 more HP through the drivetrain
• Fendt iD™ Low Engine Speed Concept: MAN 6-cylinder engines deliver rated power using less fuel by operating at lower engine speeds
• Optional Rear PTO: 1000 / 1000E rear PTO for implement compatibility

• Power Range: 511 – 673 HP across four models (1151, 1156, 1162, 1167)
• Engine: MAN 6-cylinder (15.2L or 16.2L) with Fendt iD low engine speed concept
• Max. Torque: 1,844 – 2,286 ft·lb @ 1,450 RPM
• Transmission: VarioDrive CVT — stepless from creep speed to 25 mph, no range changes required
• Fuel Capacity: 350 gal (1,320 L)

Hydraulics & Hitch

• Hydraulic Flow: 58 gpm standard — optional dual-pump, dual-circuit system at 116 gpm
• Working Pressure: 2,900 psi · up to 8 rear SCV valves
• Rear 3-Point Lift: Steerable — 20,000 lbs high-lift / 15,000 lbs standard lift capacity

Dimensions & Weight

• Weight: 42,000 lbs empty · 59,000 lbs max. permissible
• Footprint: 266 in L × 116.1 in W (standard) / 141.8 in W (wide gauge) × 148 in H
• Ground Clearance: 14.1 in

• VarioTerminal: 10.4 in display with full-screen, half-screen, split-screen, and four-in-one view, integrating tractor controls, implement controls, camera, and guidance
• Multi-Function Joystick: Four-way joystick controlling up to ten ISOBUS implement functions, plus auxiliary hydraulic controls, cruise control, and headland management activation
• Mechanical Cab Suspension: Optional coil-over shock absorbers with 4 in of travel to reduce vibration and bouncing

Suspension & Undercarriage

• Smart Ride™: Hardbar suspension with dual coil springs and heavy-duty shock absorbers — 10 in of suspension travel with independent left/right undercarriage movement
• Smart Ride Plus: Load-leveling system using hydraulic pressure to raise or lower the front end for improved weight distribution, traction, and ride quality
• Mobil-Trac™ System: 118 in wheelbase with four pivoting midwheels per side — track widths from 18 in to 36 in for draft or row crop applications

Implement Control

• Steerable Hitch: 12° of hitch movement with auto float, fixed, and offset modes — unique to Fendt
• Controlled Drawbar: 11.5° of swing with automated modes for fixed offset, offset, and float — configurable from the terminal
• Dual-Pump Hydraulics: Independent dual-circuit, load-sensing system — set different pressure and flow per pump to match implement demands

Technology & Connectivity

• Fendt Connect™: Remote fleet monitoring, real-time diagnostics, and dealer access to fault codes via smartphone, tablet, or laptop
• Fendt Task Doc® Pro: Wireless data capture and transfer seed quantity, fertilizer applied, fuel consumption, GPS position with ISOXML-compatible field files
• Fendt Rate Control / Section Control: Variable-rate application from field files and fully automatic section control for up to 36 sections on ISOBUS planters, drills, or sprayers

Warranty & Service

• Gold Star Customer Care: 3-year / 3,000-hour full-machine warranty ($0 deductible), all factory-recommended maintenance included, plus a loaner guarantee within 48 working hours
• Gold Star+ (Optional): Extends all Gold Star benefits to 5 years / 5,000 hours
